  • HY-9800 Horizontal Directional Drilling Rig

HY-9800 Horizontal Directional Drilling Rig

Main Parameters:
Ø Pull / Push Force: 9800KN/9800KN
Ø Pull / push Speed: 0~20m/min
Ø Torque: 240,000N·m (continuously)
Ø Rotating Speed: 0~35rpm
Ø Torque of Vice Clamp:318822Nm/25Mpa
Ø Drill Rod: 5“,5 ½”,6 5/8 ”
Ø Angle Range: 8°~18°
Ø Power Consumption of Generator: 550kwX2
Ø Dimension: 15000×2500×3900
Ø Weight: 78T
